Features

Built-In Dual Speakers

Built-In Dual Speakers

High-quality speakers are integrated into the OneScreen Touchscreen TL7 86" for immersive audio experience.

Multi-Touch Functionality

Multi-Touch Functionality

Multiple simultaneous touch points for promoting interactions and collaborations with the input of multiple users.

Zero Bonded Technology

Zero Bonded Technology

It offers accurate and faster responsive touch experience by eliminating the air gap between touch sensor and the display.

Anti-Glare Screen

Anti-Glare Screen

The antiglare coating on the display ensures clear visibility even in low-lit environments, reducing eye strain of users.

Anti-Fingerprint

Anti-Fingerprint

Frequent touch interactions possible with anti- fingerprint coating that ensures the screen remains smudge and stain-free.

Intuitive Touch Interfaces

Intuitive Touch Interfaces

Simplified interaction, navigation and operations with user-friendly interfaces customized to client requirements.

Plug & Play

Plug & Play

Effortless and faster setup with the plug & play connectivity method of OneScreen TL7 86” enable immediate usage.

Multi-Connectivity

Multi-Connectivity

HDMI, USB, and wireless connectivity options to integrate the display with various devices and systems.

Light Sensor

Light Sensor

Automatic light sensor adjusts the screen brightness according to the lighting conditions in the room.

omizable Interactive Display

Customizable Interactive Display

Users can access their own drive and home screen, and applications can be customized based on preference.

24/5 Live
                                Support with Guru

24/5 Live Support with Guru

Highly trained engineers, available 24/5 offer training and support through Guru app via chat, email, phone, or video.

Interoperable
                                with Existing Tools

Interoperable with Existing Tools

OneScreen Touchcreens are compatible with diverse software and tools, enabling smooth integration into systems.

Pre-Loaded Software Included
with the OneScreen Touchscreen TL7 86"

OneScreen Write

OneScreen Write

Intuitive annotation tools that allow users to draw, highlight and annotate on the content displayed or blank white board.

OneScreen Central

OneScreen Central

Cloud-based management software that enables users to manage and operate multiple devices from a central location.

OneScreen Share

OneScreen Share

Supports wireless content sharing with up to 9 devices and diverse operating systems such as iOS, Android, Windows, etc.

OneScreen Accounts

OneScreen Accounts

Create customized user profiles for better user management and securely access personal Google and Microsoft Cloud drives.

OneScreen LearningHub

OneScreen LearningHub

Enhance student engagement, record lessons, and organize hybrid teaching sessions with interactive tools and activities.

OneScreen QuizWiz

OneScreen QuizWiz

Improve learning experiences by conducting quiz competitions with AI generated quizzes created in just a few clicks.

Hardware Components

  • Interactive Display Diagonal : 86"

Computing

  • Operating System : Android 11
  • RAM : 8 GB
  • Storage : 64 GB
  • Processor : Quad-core ARM cortex A55 (up to 1.8 Ghz)

Power

  • Power Requirements : 100 - 240v AC 50-60 Hz
  • Power Consumption (typical) : 350 W
  • Power Consumption (Maximum) : 520 W

Touch

  • Touch Type : Zero Bonding IR (Gen 2)
  • Touch Points : 40
  • Touch Accuracy : 1.5 mm
  • Touch Response Time : < 7 ms

Glass

  • Surface Protection : Level 7 MoHS Anti-Glare and Anti-Fingerprint

Audio

  • Speakers : 2x 16W with stereo output

Panel

  • Resolution : 4K UHD (3840 * 2160)
  • Brightness : 400 cd/m²
  • Aspect Ratio : 16:9
  • Refresh Rate : 60Hz
  • Viewing Angle : 178°
  • Blue light filter : Yes
  • Display Colors : 1.07 Billion (10 bit)

Accessories and Mounting

  • Wall Mount: VESA Standard 800 x 600 Flush Wall mount
  • Cables & Accessories : 1x HDMI Cable, 1x Power cable, 1x USB Touch Cable, 1x Type C Cable, 2x Stylus pens with anti-bacterial coating, 1x Remote control for Display, 1x Remote control for Camera

Physical

  • Product Weight : 129.08 lbs
  • Product Dimensions L x H x W : 77.04” x 45.66” x 3.93”
  • Shipping Weight : 167.33 lbs
  • Shipping Dimensions L x H x W : 83.07” x 50.51” x 8.86”

Ports and Connectivity

  • Sensors : 1x Ambient Light Sensor for adoptive screen brightness
  • Connectivity : Wifi 6 (2.4 GHz and 5 GHz), Gigabit Ethernet (1000M), Bluetooth 5.2
  • Input/Output Ports (Side) : 2x HDMI-In, 1x VGA-In, 1x VGA Audio-In, 1x HDMI-Out, 1x USB Touch, 1x Audio-Out (3.5mm), 1x SPDIF- Out, 1x RS-232, 2x-RJ-45, 2x USB 3.0, 1x USB 2.0,1x OPS PC Slot
  • Input/Output Portsb (Front) : 1x HDMI-In, 1x USB Touch, 2x USB 3.0, 1x USB Type-C (65W PD)

Interactive Whiteboard : OneScreen Write is a powerful annotation tool with cloud drive integration, built-in browser and smart tools.

Device Management : OneScreen Central provides cloud-based multi-device management, messaging to multiple devices, apps and settings management.

Screen Sharing : OneScreen Share allows multi-device screen share and streaming. Up to 9 devices supported (iOS, Android, Windows, Chrome, MacOS).

User Profiles & Cloud Drive : OneScreen Accounts help you create customized profiles that integrate with Google and Microsoft Cloud drives.

Student Engagement and Lesson Capture : OneScreen LearningHub allows you to record lessons, build student engagement and conduct hybrid classroom sessions.

Quiz Generation : OneScreen QuizWiz helps teachers create quizzes automatically using AI in just a few clicks from content.

Lesson Resources : ZUNI Learning provides all of the best, free, online lessons & resources in one place integrated with Google Class.

Classroom Tools : Stopwatch, timer, screen recorder, spotlight, screen capture, cloud drive, freeze and multitasking.

Adminstration/IT Tools : Settings lock, OTA firmware updates, Centralized control, Network settings lock, screen lock and device cloning.

*First year of subscriptions to all cloud-based services included

The OneScreen Touchscreen TL7 86” is designed to transform the way users collaborate and learn. With this interactive display users can collaborate through multiple platforms such as Google, Microsoft, iOS, Schoology, Canvas and more. This touchscreen display offers multiple touch points, intuitive touch interfaces, integrated software, immersive visuals and audio, for creating engaging collaborative experiences. Users have the option to record sessions and presentations, save, and share them as needed for documentation or information exchange. OneScreen Touchscreen TL7 86" is BYOD friendly due to its simple connectivity and diversity of device compatibility. With its wide range of collaborative tools, OneScreen TL7 86” improves communication and learning making it ideal for both corporations and educational institutions.

Set the stage for productive interactions with OneScreen Touchscreen TL7 86".
