C9200-24PXG. Optimized for Wi-Fi 6/6E wired and wireless converged access and higher-bandwidth branch deployments. 16-port 1G, 8-port 10GBASE-T, 10G/5G/2.5G/1G multigigabit, 1000M/100M. Modular uplinks of 40G, 25G, 1G, or 10G/1G. Stackable to 160G, FRU power supplies and fans.
C9200-48PXG. Optimized for Wi-Fi 6/6E wired and wireless converged access and higher-bandwidth branch deployments. 40-port 1G, 8-port 10GBASE-T, 10G/5G/2.5G/1G multigigabit, 1000M/100M. Modular uplinks of 40G, 25G, 1G, or 10G/1G. Stackable to 160G, FRU power supplies and fans.
C9200-24PB. Ideal for improved Cisco SD-Access deployments. 24-port 1G, 30W PoE+. Modular uplinks of 40G, 25G, 1G, or 10G/1G. Stackable to 160G, FRU power supplies and fans.
C9200-48PB. Ideal for improved Cisco SD-Access deployments. 48-port 1G, 30W PoE+. Modular uplinks of 40G, 25G, 1G, or 10G/1G. Stackable to 160G, FRU power supplies and fans.
C9200-48P. Ideal for secure branch and entry-level enterprise environments. 48-port 1G, 30W PoE+. Modular uplinks of 25G, 10G, or 1G. Stackable to 80G, FRU power supplies and fans.
C9200-48PL. Ideal for secure branch and entry-level enterprise environments. 48-port 1G, 30W partial PoE+. Modular uplinks of 25G, 10G, or 1G. Stackable to 80G, FRU power supplies and fans.
C9200-24T. Ideal for secure branch and entry-level enterprise environments. 24-port 1G, data. Modular uplinks of 25G, 10G, or 1G. Stackable to 80G, FRU power supplies and fans.
C9200-48T. Ideal for secure branch and entry-level enterprise environments. 48-port 1G, data. Modular uplinks of 25G, 10G, or 1G. Stackable to 80G, FRU power supplies and fans.
C9200CX-8UXG-2X. C9200CX-8UXG-2XH. Ideal for use in limited spaces and smart buildings. 4-port 1G, 4-port multigigabit, 60W UPOE. Two 10G SFP+ fixed uplinks. AC or AC/DC options. Compact and fanless.
C9200CX-8P-2X2G. C9200CX-8P-2XGH. Ideal for use in limited spaces and smart buildings. 8-port 1G, 30W PoE+. Two 1G copper, two 10G SFP+ fixed uplinks. AC or AC/DC options. Compact and fanless.
C9200CX-12P-2X2G. C9200CX-12P-2XGH. Ideal for use in limited spaces and smart buildings. 12-port 1G, 30W PoE+. Two 1G copper, two 10G SFP+ fixed uplinks. AC or AC/DC options. Compact and fanless.
C9200CX-12T-2X2G. Ideal for use in limited spaces and smart buildings. 12-port 1G, data. Two 1G copper, one 1G CU PD, two 10G SFP+ fixed uplinks. PoE powered or optional auxiliary 80W AC or DC power adaptor. Compact and fanless.
Designed to address evolving network requirements, the Cisco Catalyst 9200 Series switches build upon the Catalyst 9000 foundation, provides intent-based networking features that adapt seamlessly to complex and dynamic network infrastructures of diverse sizes. These switches prioritize simplicity without sacrificing essential features, ensuring security, continuous operation, and streamlined IT management.
Catalyst 9200 series deliver PoE+ capabilities, with certain models supporting up to 48 ports for high-density connectivity in demanding environments.
Field-Replaceable Units (FRU), redundant power supplies, fans, and modular uplinks of Catalyst 9200 models ensure optimal performance even during a failure.
Offer flexible downlink options, supporting data, PoE+, UPOE, and UPOE with mGig for Wi-Fi 6/6E deployments and meeting diverse network demands.
The Cisco SD-Access simplifies management by facilitating centralized control, automating policy enforcement, and providing support for network provisioning.
Optional backplane stacking with support for up to 160 Gbps stacking bandwidth enhances operational efficiency, providing scalability and streamlined management.
Powered by UADP 2.0 Mini chipset, which includes an integrated CPU, the Catalyst 9200 series offer optimized scale and affordable cost structures.
The C9200 series offers enhanced security features, including AES-128 and AES-256 MACsec encryption, policy-based segmentation, and trustworthy solutions.
Easily set up the switch with PnP that simplifies new branch or campus device rollouts and updates, providing a unified and integrated offering for easy deployment.
|
|
24 ports data | 128 Gbps |
|---|---|---|
|
|
24 ports full PoE+ | 128 Gbps |
|
|
24 ports full PoE+ | 128 Gbps |
|
|
24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G) | 352 Gbps |
|
|
48 ports data | 176 Gbps |
|
|
48 ports full PoE+ | 176 Gbps |
|
|
48 Ports partial PoE+ | 176 Gbps |
|
|
48 ports full PoE+ | 176 Gbps |
|
|
48 ports full PoE+ (8 mGig ports up to 10G, 40 ports up to 1G) | 400 Gbps |
|
|
24 ports data | 56 Gbps |
|---|---|---|
|
|
24 ports full PoE+ | 56 Gbps |
|
|
48 ports data | 104 Gbps |
|
|
48 ports full PoE+ | 104 Gbps |
|
|
48 Ports partial PoE+ | 104 Gbps |
|
|
24 ports data | 128 Gbps |
|
|
24 ports full PoE+ | 128 Gbps |
|
|
48 ports data | 176 Gbps |
|
|
48 ports full PoE+ ENERGY STAR® certified | 176 Gbps |
|
|
48 Port partial PoE+ | 176 Gbps |
|
|
24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G) | 272 Gbps |
|
|
48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G) | 392 Gbps |
|
|
24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G) | 292 Gbps |
|
|
48 ports full POE+ (8 mGig ports up to 10G, 40 ports up to 1G) | 340 Gbps |
|
|
12 ports data | 70 Gbps |
|---|---|---|
|
|
12 ports PoE+ | 68 Gbps |
|
|
8 ports full PoE+ | 60 Gbps |
|
|
8 ports UPOE (4 mGig ports up to 10G, 4 ports up to 1G) | 128 Gbps |
|
|
12 ports PoE+ | 68 Gbps |
|
|
8 ports full PoE+ | 60 Gbps |
|
|
8 ports UPOE (4 mGig ports up to 10G, 4 ports up to 1G) | 128 Gbps |
| Model | Stacking support | Stacking bandwidth support | Optional Stacking hardware | Number of members | Supported stack members |
|---|---|---|---|---|---|
|
|
StackWise-160 | 160 Gbps | C9200-STACK-KIT | 8 | Other C9200 models with same license level |
|
|
StackWise-80 | 80 Gbps | C9200L-STACK-KIT | 8 | Other C9200L models with same license level |
| Model | Stacking support |
|---|---|
|
|
Stack kit for C9200 SKUs only: Two data stack adapters and one data stack cable |
|
|
Stack kit for C9200L SKUs only: Two data stack adapters and one data stack cable |
|
|
Data stack 50 cm cable (default cable with Stack Kit) |
|
|
Data stack 1 m cable |
|
|
Data stack 3 m cable |
| Model | Description |
|---|---|
|
|
2 x 25G network module |
|
|
2 x 40G network module |
|
|
4x 1G network module |
|
|
4x 1G / 10G network module |
|
|
No network module |
The Cisco Catalyst 9200 Series switches bring forth the advancements of intent–based networking and use the innovative hardware and software features of the Catalyst 9000 lineage to cater to a wider range of deployment scenarios. It features Cisco’s IOS XE operating system that facilitates automation, configuration and delivers granular visibility into network performance. Providing support for up to 48 PoE+ ports and stacking bandwidth capabilities of up to 160 Gbps, the Cisco Catalyst 9200 series switches allow enhanced scalability and flexibility. These advanced switches with precision time protocol are ideal for applications used in industrial automation, telecommunications, and financial trading networks that require seamless distribution and synchronization of time and frequency over the network. The Catalyst 9200 Series switches offer unparalleled performance, security, and scalability, enabling businesses to navigate the complexities of today's interconnected world with confidence and efficiency.
