Hyperscale Threat Intelligence and Protection for Any Digital Infrastructure

The FortiGate 2600F series features next-generation firewalls that provide extensive security capabilities without compromising performance for digital ecosystems of any scale and size. It can handle large bandwidths of data at low latency with SPU processors and FortiOS advanced operating system.

FortiGate 2600F Series

The FortiGate 2600F and FortiGate 2601F are supported by Fortinet’s custom security processing unit (SPU) and network processing ASICs for exceptional protection at low latency, even for high-bandwidth networks. The SPU NP7 and SPU CP9 facilitate high throughput, best firewall performance, rapid SSL inspection and incident response. The ASIC architecture also assists in maintaining speed and performance, even when multiple security features are enabled.

AI/ML-powered deep packet inspection and application control offer granular visibility for monitoring network traffic, guaranteeing adherence to security regulations and optimal management of bandwidth. Anti-malware software and intrusion prevention systems (IPS) aid in the early detection and prevention of suspicious interventions. SSL/TLS inspection proactively decrypts and inspects encrypted traffic to find and eliminate malware, viruses, or any other hidden risks.

Dynamic segmentation and VXLAN segmentation for end-to-end security across dispersed locations with scalable and low-latency performance. FG 2600F, FG 2601F and other models of the series feature port density for better connectivity in an affordable range. With FortiGate 2600F and FortiGate 2601F, IT managers get the advantage of easy management and control via FortiManager.

System Performance and Capacity

  • IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) : 198 / 196 / 140 Gbps
  • IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) : 198 / 196 / 140 Gbps
  • Firewall Latency (64 byte, UDP) : 3.41 μs
  • Firewall Throughput (Packet per Second) : 210 Mpps
  • Concurrent Sessions (TCP) : 24 Million / 40 Million*
  • New Sessions/Second (TCP) : 1 Million / 2 Million*
  • Firewall Policies : 100 000
  • IPsec VPN Throughput (512 byte) : 55 Gbps
  • Gateway-to-Gateway IPsec VPN Tunnels : 20 000
  • Client-to-Gateway IPsec VPN Tunnels : 100 000
  • SSL-VPN Throughput : 16 Gbps
  • Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) : 30 000
  • SSL Inspection Throughput (IPS, avg HTTPS) : 20 Gbps
  • SSL Inspection CPS (IPS, avg. HTTPS) : 16 000
  • SSL Inspection Concurrent Session (IPS, avg HTTPS) : 2.7 Million
  • Application Control Throughput (HTTP 64K) : 64 Gbps
  • CAPWAP Throughput (HTTP 64K) : 62.5 Gbps
  • Virtual Domains (Default / Maximum) : 10 / 500
  • Maximum Number of FortiSwitches Supported : 196
  • Maximum Number of FortiAPs (Total /Tunnel) : 4096 / 2048
  • Maximum Number of FortiTokens : 20 000
  • Maximum Number of Registered FortiClients : 20 000
  • High Availability Configurations : Active-Active, Active-Passive, Clustering

Interfaces and Modules

  • Hardware Accelerated 10 GE / GE RJ45 Ports : 1 6
  • Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots : 16
  • Hardware Accelerated 100 GE QSFP28 / 40 GE QSFP+ Slots : 4
  • Hardware Accelerated 10 GE SFP+ / GE SFP HA Slots : 2
  • GE RJ45 Management Ports : 2
  • USB 3.0 Port : 1
  • Console RJ45 Port : 1
  • Onboard Storage : No(FG-2600F/-DC ) | 2x 1 TB NVMe SSD(FG-2601F/-DC)
  • Trusted Platform Module (TPM) : Yes
  • Included Transceivers : 2x SFP+ (SR 10 GE)

System Performance — Enterprise Traffic Mix

  • IPS Throughput : 31 Gbps
  • NGFW Throughput : 27 Gbps
  • Threat Protection Throughput : 25 G b ps

Dimensions and Power

  • Height x Width x Length (inches) : 3.5 x 17.25 x 21.1
  • Height x Width x Length (mm) : 88.4 x 438 x 536
  • Weight : FG-2600F/-DC 30.6 lbs (13.9 kg) | FG-2601F/-DC 30.9 lbs (14.0 kg)
  • Form Factor : Rack Mount, 2RU (supports EIA/non-EIA standards)
  • AC Power Supply : 100–240VAC, 47/63 Hz
  • Power Consumption (Average / Maximum) : 416 W / 510 W(FG-2600F/-DC) | 420.3 W / 513.7 W(FG-2601F/-DC)
  • Current (Maximum) : 6A
  • Heat Dissipation : 1740 BTU/h (FG-2600F/-DC) | 1754 BTU/h (FG-2601F/-DC)
  • Redundant Power Supplies (Hot Swappable) : Yes (Default dual AC PSU for 1+1 Redundancy)
  • Power Supply Efficiency Rating : 80Plus Compliant

Operating Environment and Certifications

  • Operating Temperature : 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -31°F to 158°F (-35°C to 70°C)
  • Humidity : 10% to 90% non-condensing
  • Noise Level : 71.72 dBA
  • Forced Airflow : Side and Front to Back
  • Operating Altitude : Up to 10 000 ft (3048 m)
  • Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
  • Certifications : USGv6/IPv6
* Requires Hyperscale Firewall License
